120-0004-01-0
D4
Model
120-0004-01-0d
D4
4K native professional AV presentation switching
PROAVvideo presentationprocessorsvideo processorvideo scalersvideo switchers
Product Overview
Understand this product quickly
Designed to streamline signal management in live and installed environments, supports versatile source connections, delivers flexible display routing, offers standard industry interfaces for integration, provides scaling, switching and control capabilities as specified, operates with the supplied power configuration, 4K HDR Dual Channel Presentation Switcher, standard with two standard HDMI 2.0 outputs.
Inputs module options, sold separately, include HDMI 2.0, 12G-SDI & DisplayPort. Output extension/mirror modules, sold separately, dual 12G-SDI, dual DisplayPort & quad DVI.
Up to 8K2K output splicing
Internal YUV4:4:4 processing
HDR 10, HLG & HDR 2.x Support
4K EDID Management
Multi-Mode Operation
SKU and Configuration
Models and options
Input option4
191-0004-02-0
Dual HDMI 2.0 Input Module
Input option
191-0004-04-0
Dual 12G-SDI Input Module
Input option
191-0004-01-0
Dual DP1.2 Input Module
Input option
191-0004-03-0
Dual 3G-SDI Input Module
Input option
| 191-0004-02-0 | Dual HDMI 2.0 Input Module | Input option | |
| 191-0004-04-0 | Dual 12G-SDI Input Module | Input option | |
| 191-0004-01-0 | Dual DP1.2 Input Module | Input option | |
| 191-0004-03-0 | Dual 3G-SDI Input Module | Input option |
Output option3
191-0004-21-0
DP 1.2 Output Module
Output option
191-0004-22-0
12G-SDI Output Module
Output option
191-0004-23-0
DVI (Quad) Output Module
Output option
| 191-0004-21-0 | DP 1.2 Output Module | Output option | |
| 191-0004-22-0 | 12G-SDI Output Module | Output option | |
| 191-0004-23-0 | DVI (Quad) Output Module | Output option |
